The Considerate Data Modeler

What’s your hot take on relational databases?

I have an opinion on the matter, or maybe more like an Opinion™: Data modeling is closer to library science than computer science. No one is impressed by a librarian who gets creative and files cookbooks under “G” for “Gourmand.” The best catalog system is where everything is in an obvious place, where everything conforms to expectations. The best librarian is considerate of the patrons. The best library is calm, safe, and boring. And the best database is exactly the same.

As Alec Baldwin’s database consultant explained to a team of application developers in Glengarry Glen Ross, it comes down to three simple letters, ABC:

Always think of your users first. Not just the application users, who are insulated from your database by an ablative layer of code and really only have one POV anyway, but also the DBAs who have to do backups, the engineers who have to build pipelines, the analysts who run queries, and executives who look at dashboards. Think about what really makes a database user happy. Hint: it’s not using all the latest features.

All of these types of users rotate your data 90° and look at it through their own lenses. That’s why relational databases and third normal form are so successful in practice; they make these conceptual rotations easy and natural.

Remember that the container is not the contents. Your data might live in a particular RDBMS today, but tomorrow it will be in Spark or Snowflake or SQL Server. Therefore, always target the lowest common denominator. Even ANSI SQL isn’t the LCD; you want to be targeting the subset of the subset of ANSI SQL which is truly portable.

Why? Because your data is eventually going to end up in another RDBMS, pumped over an ETL pipeline to a data warehouse of some kind by a tool like ADF. Any unique, advanced feature of a database that you use will cause headaches and make you enemies.

I know this firsthand because at one time or another I’ve been on every side. I’ve been the application developer who used PostGIS spatial types in my application and had to explain to the data team why spherical coordinate systems, polygons, and R-trees were absolutely essential and, no, we couldn’t just use:

    latitude NUMERIC(8,2),
    longitude NUMERIC(8,2)

even if that’s the standard for their data warehouse. I’ve also been the data scientist parachuted into a hostile operational database and given three days to write a query to extract usable training data for a machine learning model and wincing over every JSON extraction. And I’ve been the guy who advocated for building a single data warehouse from three different databases built by different people at different companies before they were acquired and merged, and had to deal with the impedance mismatch that resulted. (If I never hear the phrase “conformed dimension” again in my life it will be too soon.) So I can tell you this with great confidence:

Nobody likes a smart alec. Nobody ever says, “wow, you sure leveraged the heck out of that unique, proprietary feature from your vendor of choice! It was a great business decision to lock us in like that, and we’re really enjoying learning the ins and outs of every quirk of your very special database! And the ETL team, oh, they’re just having great fun writing custom mapping logic! They were getting so bored using the default copy activity all the time!” No, they just grit their teeth, smile, and ask how it can be mapped back to third normal form.

Case Study: Enum

Let’s do an example. MySQL and Postgres have an enum type; Oracle, Databricks Delta, and Snowflake do not. But we’re using Postgres, and enum seems like it was designed to model categorical types. Seems like a no-brainer, right?

Except your data won’t stay in Postgres, so your data model, in the abstract, will need to be ported somewhere else, like Databricks Delta Lake. When that happens, the poor DBA will have to model your enum as strings with a CHECK constraint.

Think also of the poor analysts and data scientists who have to actually use your database. SQL is their mother tongue and they think nothing of adding a couple of LEFT JOIN clauses to pick up human-readable columns… at the end of their query. In the meat of the logic, all the CTAS statements and subqueries, they want to use fast, exact joins on primary keys.

Here’s some homework for you:

1) I want to deprecate a value in an enum, but it is used in historical data and still meaningful there. If it were a lookup table we could add a soft delete flag; how do I do the same thing with enum?

2) I need to associate additional information with each code in my enum. For example, I have a State enum, but I also need to store the two-letter state abbreviations, and distinguish between states and territories. How would I do that with an enum?

3) Write a query that returns one row for every state in the State enum and counts the number of orders. To be clear, it should return a row even for states where the count is zero, like ('Wisconsin', 0). Compare your answer* to this query:

SELECT state.name, COUNT(orders.id) AS n_orders
FROM state
LEFT JOIN orders ON state.id = orders.state_id
GROUP BY state.name

Which one would you prefer?

Keep it Boring

If the answer to every question about how to handle problems is “use a lookup table,” why not start with that in the first place? 3NF is popular precisely because it tends to not get in trouble in this way.

You might argue, well, why don’t we start with enum today, but then migrate when these cases actually come up in practice. YAGNI! KISS!

The problem there is that the refactoring isn’t transparent at all. Relational databases have an “interface,” just like an API; that’s why we can swap tables for views, for example. But the surface area of that interface is quite large: every table name, column name, and type.

Going from an enum to a lookup table is a backward-incompatible change in the interface to the database. Every single SQL query that ever touched that enum will need to be rewritten. That means the custom maps in ETL pipelines, ORM models in application code, every snippet of saved SQL the analysts keep inside of DBeaver to quickly answer ad hoc questions from executives.

But let’s say you push through the change management nightmare and get the State enum refactored to the state_id column, or whatever. Now you have a data model where some columns use enum, some use the lookup table convention, and everyone has to check every single time they use any column. Well-designed data models follow clear conventions so that you hardly ever have to think.

Here is something absolutely key for application developers to understand: the database is not for just you. It is not your private vault to persist a few objects so your application works. It is an integral part of your interface to the rest of the organization, the back office in particular. If your application is successful, executives will want dashboards with metrics, analysts will want to do reporting, and data scientists will want to extract training data.

If it’s painless to migrate, it’s only because no one was using your data in the first place. Your database was already a failure. (Obviously this only applies to data that you intend to share with others. If you’re working on a hobby project you can do as you like.)

Conclusion

What if there were a better way? What if, and hear me out on this, we just… didn’t do it? Any of that complex stuff? What if we just built plain ol’ boring data models in 3NF that used precisely zero advanced features and can therefore be trivially instantiated on any RDBMS using conventions that everyone in the industry is familiar with? It would be like coming home to your favorite little library, where everything is in its proper place be and you can always find what you’re looking for, where all the customers are happily browsing, the staff is relaxed, and even the cat seems to know in its heart that it’s exactly where it should be.

ABC: Always Be a Considerate data modeler. Design boring databases.

Footnotes

* Answer to homework question 3 in PostgreSQL:

SELECT state.name, COUNT(orders.id) AS n_orders
FROM unnest(enum_range(NULL::state)) AS state(name)
LEFT JOIN orders ON orders.state = state.name
GROUP BY state.name

Back
